C8476

If you’ve ever gone back to your motorhome or campervan and found that the starter battery has mysteriously discharged, a Votronic Battery Master could well be what you need. We have two models, both of which take a charge from the leisure battery and send it to the starter battery as required. C8451 can be used in many vehicles that have lead-acid leisure batteries, but it’s not suitable for use with lithium batteries as there is no control over either the input or the output.

Lithium (LiFePO4) batteries have a significantly higher resting voltage than starter batteries (lead, AGM). When using simple, unregulated standby chargers, this can lead to the lithium supply battery being completely drained. In this case, the Votronic standby charger (C8451) is not suitable.

The Votronic Battery Master PRO (C8476) has an adjustable undervoltage limit at the input. The charging is interrupted if this voltage falls below this level, making it ideal for use with lithium leisure batteries. The other main difference between this unit and the standby charger (C8451) is the adjustable output current – up to 8 Amps. This high current ensures that, as long as there’s sufficient capacity in the leisure battery, the starter battery it’s connected to will be maintained at a good state of charge.

Main Features:

• Charging converter for recharging and maintaining charge of the starter battery
• IU charging characteristic
• Adjustable final charging voltage of 12.5 – 14.5 V
• Up and down conversion from input to output voltage possible
• Also works if the voltage of the battery to be supplied is lower than that of the battery to be charged
• An adjustable switch-off threshold of 12 – 14 V on the input side prevents the battery connected on the input side from being completely discharged
• Suitable for lead, gel, AGM and lithium (LiFePO4) batteries at both the input and output
• Strong output current of max. 8 A
• Passive cooling without fans
• Two independent 12V control inputs:
• “EN” (enable), to activate
• “DIS” (disable) to deactivate
• Standby charger can therefore be switched on externally via a switch and switched off, for example, using D+ while driving
• 2 LEDs provide information about the operating status
• Safe to operate thanks to built-in overheating protection
